Bushed Hole Positioner
20177

Used for positioning pins and other locators in open setups
  • Stevens Precision Bushing may be positioned anywhere.
  • Ideal for locating parts for inspection and light machining operations.
  • Used to establish pickup locations instead of drilling and boring construction holes.
  • Thickness is qualified, allowing its use as a height locator as well as a bushed hole locator.
  • Material: Alloy steel, case hardened to 60Rc.
Part Number
Description
CAD
download
Cost
USD
20177
BUSHING POSITIONER
File Request
20177
$101
