Micro Jack
20191

Compact, low-profile jack used for leveling heavy workpieces
  • The worm and worm gear lifting mechanism allows extremely fine height adjustment. Loads up to 5,000 pounds are easily lifted.
  • Total stroke of the plunger is .250 inches. A threaded hole in the top of the plunger allows addition of any combination of Stevens rest pads, toggle pads, and risers.
  • Often used in combination with three rest pads to provide a solid four-point support for a casting that would wobble on 4 fixed height rest pads. It can be adjusted for each casting as it is set up for machining.
Part Number
Description
CAD
download
Cost
USD
20191
MICRO JACK ASSEMBLY
File Request
20191
$586
